The Double Door metal Electrical Cabinet range are robust, vandal resistant and manufactured to a very high quality. These metal enclosures have a design that incorporates flush fitting hinges and hidden ventilation yet it provides an ingress protection rating of IP65. The door lends itself easily to lock customisation, while the neat radius corners create a quality design that looks timeless on any street.
Flush fitting doors
Fabricated from 3mm mild steel
Variety of locking mechanisms
Plinth mounted or surface / wall mounting available
Radiused corners eliminates sharp edges
Fully lined door aperture
IP65 Rated door seal with IP42 ventilator
Hot dipped galvanised finish to BS EN ISO 1461
Standard locks supplied are Crown Insert Lock or Tri Cam Lock, others available on request.
Fitted with back board made from 12 mm external grade plywood.
Stainless steel earth terminal and earth strap between cabinet and door.
Heavy duty door hinges secured with stainless steel pins and nylon bushes.
EDPM Door seal 20 mm wide x 10 mm thick.
